Base Station Antenna Series
M.gear Base Station Antenna Series: High-Performance Multi-Band Connectivity
M.gear offers a comprehensive portfolio of high-performance base station antennas designed to meet the evolving demands of modern telecommunications. From compact dual-band units to complex hexa-band systems, our antenna solutions provide reliable, high-gain coverage across a wide range of global frequency spectrums, including LTE and advanced 5G NR bands. Engineered for precision and durability, M.gear antennas empower operators to optimize network capacity while minimizing their physical footprint on site.
Specifically tailored for the following applications and market demands
- Multi-Standard Network Integration: Supports a wide array of configurations, including Dual-Band, Triple-Band, Quad-Band, Penta-Band, and Hexa-Band, to facilitate the coexistence of 2G, 3G, 4G LTE, and 5G technologies.
- 5G Deployment & Expansion: Specialized designs for FDD and TDD architectures, including dedicated 3.5GHz solutions (TDD 3.5GHz) and hybrid FDD/TDD configurations to accelerate 5G rollout.
- High-Density Urban Coverage: Offers beamwidths (e.g., $60^{\circ}$–$68^{\circ}$ Horizontal Half-Power Beamwidth) optimized for sectorized cell sites to maximize user capacity in crowded environments.
- Infrastructure Optimization: By integrating multiple frequency bands (from 698MHz up to 3800MHz) into a single radome, our antennas reduce tower load and site leasing costs.
Superior performance and reliability in the field
- Precision Beam Control: Our antennas feature Fixed Electrical Downtilt (ranging from 2° to 4° ) and high Front-to-Back ratios ( ≧ 22dB ), ensuring precise signal targeting and significantly reduced co-channel interference.
- Advanced Interference Mitigation: With port-to-port isolation of ≧ 25dB and low passive intermodulation (IMD3 ≦ -150dBc), M.gear ensures clean signal transmission and high data throughput even in complex multi-carrier environments.
- Industrial-Grade Reliability: Utilizing high-quality Fiberglass radomes and DC-ground lightning protection, our products are rated for extreme wind speeds (up to 200 km/h) and wide temperature ranges (-40℃ to +65℃ ), ensuring long-term operational stability.
- Standardized Quality: All performance metrics are calculated according to NGMN Alliance BASTA/BTS standards, reflecting our commitment to transparent, industry-leading technical accuracy.
