Outdoor
High-Performance Antenna Solutions Empower the Core of Outdoor IoT:
In the unpredictable world of outdoor environments, stable wireless connectivity is the heartbeat of every device. M.gear’s outdoor antenna solutions go beyond peak signal gain and efficiency—we define our products through the lens of absolute reliability.
Specifically engineered for Outdoor Networking and Industrial IoT applications, our solutions are built on four core pillars of excellence:
Extreme Weatherproof Protection:
Certified with IP67/IP69K ratings, our antennas feature UV-resistant, anti-corrosive materials and wide-temperature tolerance to ensure stable operation in the harshest natural conditions.
High-Integration Multi-Band Technology:
Supporting 5G, 4G LTE, Wi-Fi 7, GNSS, and specialized long-range Wi-Fi HaLow, our multi-port designs reduce installation footprints and lower long-term maintenance costs.
Agile Customization Capabilities:
Whether for smart street lighting, vehicular systems, or remote monitoring stations, we provide deep tuning of cables, connectors, and frequency bands to ensure a "seamless upgrade" for your existing infrastructure.
Global Manufacturing & Scalability:
Leveraging our manufacturing hubs in Taiwan, Vietnam, and China, we deliver high-efficiency turnaround from initial prototyping to large-scale mass production.
Whether you are looking to expand coverage or overcome interference challenges, M.gear is your trusted partner in RF engineering.
- RF Bands: 1710-2690 | 3300-3800 MHz | Omni-Directional
- Gain: 6 to 9 dBi | Polarization ± 45-Degrees
- Public and Private LTE/5G small cell and DAS networks in outdoor city areas, hospitals, hotels and airport terminals
- Frequency Range: 1710-2690 | 3300-3800 MHz
- Gain: 16.9 to 18 dBi | Multi-Beam | Polarization ± 45-Degrees
- High gain antennas that are ideal for large outdoor areas such as stadiums, highways, high speed rail.
- Frequency Range: 698-803 | 880-960 | 1710-2690 MHz
- Gain: 13.5 to 18 dBi | Directional | Polarization ± 45-Degrees
- MIMO Configurations: 2x2, 3x3, 4x4
- Indoor/outdoor LTE/5G mobile and fixed wireless broadband networks
- Frequency Range: 698-896 | 1710-2690 MHz
- Gain: 11 to 17.5 dBi | Multi-Beam | Polarization ± 45-Degrees
- Indoor and outdoor LTE and 5G mobile broadband networks
- Frequency Range: 698-960 | 1710~2690 | 3300 – 3800 MHz
- Gain: FDD – 10.4-14 dBi, TDD - 15.1-15.2 dBi | Directional
- Outdoor and large indoor venue LTE and 5G mobile and fixed wireless broadband networks
- Frequency Range: 1710-2690 MHz
- Gain: 13.8-17 dBi | Directional | Polarization ± 45-Degrees
- Space-saver antenna with support for mobile and fixed wireless broadband networks
- Frequency Range: 5GNR n77/n78/n79
- Gain: 12-15 dBi | Omni and Sectorized (33, 65, 90 and 120 Degrees)
- Outdoor and large indoor small cell deployments for warehouses, parking lots, mining, streetscapes and manufacturing facilities
